What is a graph?

A graph is a datatype similar to a tree – it has nodes (also called 'vertices') and edges that connect them, like a tree. Where they differ is that the edges of a graph can be bidirectional (but aren't always) and graphs do not have a top-down structure. Additionally, the edges of a graph can have an associated weight, which can be thought of as the cost of moving along a particular edge. When all the edges in a graph are one-way, we call this a directed graph or digraph.

We can define a graph with the notation \(G = (V, E)\), where \(V\) is a set of vertices and \(E\) is a set of edges that describe relationships between those vertices. Each edge in is a tuple consisting of two vertices \((v1, v2)\), where \(v1, v2 \in V\) (\(v1\) and \(v2\) are members of set \(V\)). We can also add a third component to each edge, its weight value. A subgraph \(s\) is a set of vertices \(v\) and edges \(e\) where \(v \subset V\) and \(e \subset E\) (\(v\) is a subset of \(V\) and \(e\) is a subset of \(E\)).

For example, we could define the following graph:

$$V = \{v0, v1, v2, v3, v4, v5\}$$

$$ E = \{(v0,v1,5), (v1,v2,4), (v2,v3,9), (v3,v4,7), (v4,v0,1), (v0,v5,2), (v5,v4,8), (v3,v5,3), (v5,v2,1)\}$$

Which describes the following layout:

With our graph defined, we can now follow a path from one vertex to another. We would define a path as \(e_1, e_2, ..., e_n\) where \((e_i, e_i+1) \in E\). With a path defined, we can calculate two separate values known as the unweighted path length which is the total number of edges in the path, and the weighted path length which is the sum of the weights of all the edges in the path. For example, if we were to follow the path that takes us from \(v3\) to \(v1\), the sequence of vertices we must visit is \((v3, v4, v0, v1)\) along the path \(\{(v3,v4,7), (v4,v0,1), (v0,v1,5)\}\) which has an unweighted path length of 3 and a weighted path length of 13.

When working with a directed graph such as the one above, we can encounter a cycle which is simply a path that begins at one node and leads back to the same node. For example, the sequence of vertices \((V5, V2, V3, V5)\) is a cycle. A graph without any cycles is called an acyclic graph, and a directed graph without any cycles is called a directed acyclic graph, or DAG.
